EZ-Tagchecker Duo

Dual-channel tag production Quality Measurement Instrument

Ø Specialized equipment for tag production test automation.

Ø Supports dual-channel simultaneous work and high space utilization;

Ø Supports a -25 to 25dBm power adjustment range.

Ø Power adjustment step 0.25dB.

Ø Supports 840～960 MHz frequency range (expandable to 800～1100 MHz).

Ø Supports tag conformance testing at up to 10 frequency points.

Ø Support tag conformance + TID combination test.

Ø Tag conformance test for 2 frequency points in as fast as 14ms.

Ø GPIO signal triggers to read 96bit EPC plus 96bit TID, with a maximum speed of 15ms/time.

Ø Read 96bit EPC plus 96bit TID continuously, with a maximum speed of 8ms/time.

Ø Supports external jitter-triggered tag filtering.

Ø Supports NPN and PNP type rising or falling edge external triggering.

Ø Support PASS/FAIL test signal output.

Ø Support network port or RS232 serial port communication mode.
